Home > Case Studies > Gas Blower Housing - Aluminum Pressure Die Casting Services Case Study

Gas Blower Housing- Aluminum Pressure Die Casting Services Case Study



Aluminum HousingServices: Steel Tooling & Aluminum Pressure Die Casting Services

Part Size: 213.4mm * 232.5mm * 55mm

Tooling Material: H13 Hardening

Tooling Lead Time: 25 calendar days

Casting Material: ADC 12

Production Lead Time: 4 days

Quantity: 110





About The Part

Tooling



The aluminum housing was designed to protect components inside. It expected with minimum vibrations during working, so tight tolerance is necessary, especially for the critical dimensions which bears on parts proper assembly and working directly. Die casting mold design

and Aluminum Die Casting process control are important link for parts quality.



About The Customer



The customer is a worldwide innovation leader in fans and motors with over 15,000 different products, the group has the ideal solution for virtually all air technology and drive engineering tasks. Their business scope includes Agriculture, Air-conditioning and Ventilation, Appliance, Automotive, Commercial Refrigeration, Heating, Industrial, Lighting, IT / Telecom, Medical, Transportation and more. For this project, they would like to start with a prototype Aluminum Die Casting mold to verify the new design and have a low volume manufacturing parts. We quoted to the customer, he was happy with our price and lead-time.




Casting Manufacturer Starts with DFM (Design for Manufacture Ability) Report


TEAM Rapid as a professional casting manufacturer, we can provide strong engineering supports to our customers, this greatly cuts down potential quality risks that limit product launching quickly. For this project, our engineers got back DFM to the customer the same day we received the PO. We list out the suggested parting lines, gate & overflows location, ejector location, draft etc in the report, this could help the customer insight into how we would build his mold.


Gate   Parting Line   Ejection   Draft



About Our Aluminum Pressure Die Casting Services


TEAM Rapid is dedicated to provide the best Die Casting Services and supports to our customers worldwide. We take care of every small detail from die design & fabrication to parts shipment:

Aluminium Pressure Die Casting Services


1. Being inAluminum Die Casting over 10 years.

2. Unlimited parts quantity.

3. Free of charge for engineering supports.

4. Apply with ISO9001:2015 standard, 100% inspection.

5. Advanced manufacturing facility.

6. Custom services accept ODM and OEM.

7. Low cost, price 10% lower than most Die Casting Manufacturer.

8. Delivery on time, anual output reached 1000 tons.


Looking for pressure die casting services?Mail us at [email protected] to get supports now!




Kick Off The Tool Building



Customer approved the DFM, they were happy with our tooling proposal. This Aluminum Die Casting mold consists of cavity, core and 1 slider. As the mold would work under harsh condition, the mold needed to be strong enough to withstand high pressure and temperature. Mold heat treatment / hardening is necessary, this process was proceeded after semi machining on cavity, core and slider, fine machining & EDM would be later after mold heat treatment. Building a pressure die casting mold usually takes a long time, it involves a series of processes such as CNC machining, EDM machining, heat treatment, mold fitting etc. At TEAM Rapid, we can shorten the die casting mold rapid manufacturing lead-time to 10-25+ calendar days by our rich experience and superb skill.

CNC Machining   Drilling   EDM   Fitting

             Mold CNC Machining                               Mold Drilling                                Mold EDM Machining                                Mold Fitting


Aluminum Die Casting



The die casting mold was on the machine and ready to cast, we poured the melted aluminum from a crucible into the sleeve. The liquid aluminum was injected into the cavity under setting pressure. From clamping, casting, cooling, ejection, we got the cast part successfully. After going a step further casting parameters optimization, the part's cycle time was locked down at 42 seconds. We ran these small batch Aluminum Die Casting parts smoothly at the T1. The gate and overflows were wiped off after ejection by post machining.

Aluminum Pressure Die Casting   Pressure Die Casting Part   Aluminum Casting

                              Mold Trial                                                              Casted Part                                           After Removing Gate & Overflows



Post Finishing



The part needed in free of flashes, we processed the viber polishing after wiping off the gates and overflows.

Viber Polishing       Part

                                Viber Polishing                                                                           Finished Part



Applications of this Die Cast Part


Pressure Die Casting Project At TEAM Rapid


Are you ready to get started on your next project? TEAM Rapid is a Aluminum Die Casting Manufacturer in China, Contact us at [email protected] for a free quote.
